Technical Data
Pushbutton
4 single pressure motion buttons
4 single pressure motion buttons
Weight
approx. 78g
Size
79×45.7×23.5 mm
Frequency band
315 / 418 / 429 / 433 / 447 / 470 / 915 MHz / 2.4 GHz
315 / 418 / 429 / 433 / 447 / 470 / 915 MHz / 2.4 GHz
Channel space
12.5 kHz
Number of available on/off command
max. 24 + Start and EMO
Hamming distance
≥ 15
Radio communication
bi-directional
Frequency handling
Automatic and dynamic switching between 2 channels
Power supply
LR3(AAA)1.5V / NiMH(AAA)1.2V x2
LR3(AAA)1.5V / NiMH(AAA)1.2V x2
Stop command response time
~ 50 ms
Command response time
~ 50 ms
Protection degree
IP65
Operating and storage temperature
(-25°C)~(+55°C) / (-40°C)~(+85°C)
Housing material
PA6 (GF30%)
