Technical Data
Pushbutton
2, 4, 6, 8,10, 12 single / double pressure motion buttons
2, 4, 6, 8,10, 12 single / double pressure motion buttons
Weight
approx. 241g (2-4 buttons)
approx. 283g (6-8 buttons)
approx. 296g (10-12 buttons)
Size
161×60×28mm(2-4 buttons)
204×60×28mm(6-8 buttons)
249×60×28mm(10-12 buttons)
Frequency band
315 / 418 / 429 / 433 / 447/ 470/ 868 / 915 MHz / 2.4 GHz
315 / 418 / 429 / 433 / 447/ 470/ 868 / 915 MHz / 2.4 GHz
Channel space
12.5 / 200kHz
Number of available on/off command
max.24 + EMO
Hamming distance
≥ 15
Radio communication
bi-directional
Frequency handling
Automatic and dynamic switching between 2 channels
Power supply
LR6(AA)1.5V x4
LR6(AA)1.5V x4
Stop command response time
~ 50 ms
Command response time
~ 50 ms
Protection degree
IP65
Operating and storage temperature
(-25°C)~(+55°C) / (-40°C)~(+85°C)
Housing material
PA6 (GF30%)
