Technical Data
Pushbutton
8 single pressure motion buttons
8 single pressure motion buttons
Weight
approx. 226g
Size
240×44×25mm
Frequency band
315/ 418/ 429/ 433/ 447/ 470/ 868/ 915 MHz / 2.4 GHz
315/ 418/ 429/ 433/ 447/ 470/ 868/ 915 MHz / 2.4 GHz
Channel space
200K
Number of available on/off command
8 + EMO
Hamming distance
≥ 15
Radio communication
bi-directional
Frequency handling
Automatic and dynamic switching between 2 channels
Power supply
LR6(AA)1.5V x4
LR6(AA)1.5V x4
Stop command response time
~ 50 ms
Command response time
~ 50 ms
Protection degree
IP65
Operating and storage temperature
(-25°C)~(+55°C) / (-40°C)~(+85°C)
Housing material
PA6 (GF30%)
